Live component. Click, hover, and type to try it.
Install
npx shadcn@latest add https://mdxcn.dev/r/graph-bars.jsonAbout
Before/after bar comparison with a processor in the middle.
Live component. Click, hover, and type to try it.
npx shadcn@latest add https://mdxcn.dev/r/graph-bars.jsonBefore/after bar comparison with a processor in the middle.
"use client"
import type { ReactNode } from "react"
import { motion, useReducedMotion } from "motion/react"
import { GraphArrow } from "@/registry/default/graph-frame/graph-arrow"
import {
childItems,
defineItem,
Graph,
GraphBody,
hasHost,
itemText,
listItems,
numbers,
splitLabel,
textOf,
} from "@/registry/default/graph-frame/graph-frame"
import {
fillDelay,
graphTransition,
toneClass,
trackMarks,
type Glyphs,
type GraphPalette,
} from "@/registry/default/graph-frame/graph-motion"
import { cn } from "@/lib/utils"
type BarSeries = {
label: string
values: number[]
size?: "sm" | "lg"
}
type SeriesProps = {
label: string
values?: number[] | string
size?: "sm" | "lg"
}
/** `<Series label="before">2 4 3 5 2</Series>` — first is from, second is to. */
const Series = defineItem<SeriesProps>("Series")
type GraphBarsProps = {
title: string
/** Left series. Or write two `<Series>` children. */
from?: BarSeries
/** Right series. Or write two `<Series>` children. */
to?: BarSeries
children?: ReactNode
processor?: string
glyphs?: Glyphs
palette?: GraphPalette
corner?: string
className?: string
}
function MiniBars({
values,
height,
delay = 0,
tone = "accent",
fill,
palette,
}: {
values: number[]
height: number
delay?: number
tone?: "accent" | "muted"
fill: string
palette?: GraphPalette
}) {
const reduce = useReducedMotion()
const max = Math.max(...values, 1)
return (
<div className="flex items-end gap-1">
{values.map((value, index) => {
const level = Math.round((value / max) * (height - 1))
return (
<span className="flex w-[1ch] flex-col justify-end" key={index}>
{Array.from({ length: height }, (_, row) => {
const fromBottom = height - 1 - row
const on = fromBottom <= level
return (
<motion.span
className={cn(
"h-[1em] w-full text-center",
on
? tone === "accent"
? toneClass(palette, "primary")
: toneClass(palette, "secondary")
: "text-transparent"
)}
initial={reduce || !on ? false : { opacity: 0 }}
key={row}
transition={graphTransition(reduce, {
delay: delay + fillDelay(reduce, index, 0.03),
})}
viewport={{ once: true }}
whileInView={{ opacity: 1 }}
>
{on ? fill : " "}
</motion.span>
)
})}
</span>
)
})}
</div>
)
}
function GraphBars({
title,
from: fromProp,
to: toProp,
children,
processor,
glyphs,
palette,
corner,
className,
}: GraphBarsProps) {
const listed = listItems(children).map((item) => {
const { label, rest } = splitLabel(itemText(item))
const content = (item.props as { children?: ReactNode }).children
return {
label: label || itemText(item),
values: numbers(rest),
size: hasHost(content, ["strong", "b"]) ? ("lg" as const) : undefined,
}
})
const tagged = childItems(children, Series).map((entry) => ({
label: entry.label,
values: numbers(entry.values ?? textOf(entry.children)),
size: entry.size,
}))
const series = listed.length > 0 ? listed : tagged
const empty: BarSeries = { label: "", values: [] }
const from = fromProp ?? series[0] ?? empty
const to = toProp ?? series[1] ?? empty
const marks = trackMarks(glyphs)
const fromHeight = from.size === "lg" ? 8 : 5
const toHeight = to.size === "lg" ? 8 : 5
return (
<Graph title={title} className={className} corner={corner}>
<GraphBody>
<div className="flex flex-col items-center gap-8 sm:flex-row sm:items-end sm:justify-center sm:gap-8">
<div className="flex flex-col items-center gap-3">
<MiniBars
delay={0.04}
fill={marks.fill}
height={fromHeight}
palette={palette}
tone="muted"
values={from.values}
/>
<p className={toneClass(palette, "secondary")}>{from.label}</p>
</div>
<div className="flex items-center justify-center gap-3 text-graph-muted max-sm:rotate-90">
<GraphArrow />
{processor ? <span>{processor}</span> : null}
<GraphArrow />
</div>
<div className="flex flex-col items-center gap-3">
<MiniBars
delay={0.16}
fill={marks.fill}
height={toHeight}
palette={palette}
values={to.values}
/>
<p className="text-foreground">{to.label}</p>
</div>
</div>
</GraphBody>
</Graph>
)
}
export { GraphBars, Series }
export type { BarSeries, GraphBarsProps, SeriesProps }
