Task CardNew
Live component. Click, hover, and type to try it.
Install
npx shadcn@latest add https://pinui.xyz/r/task-card.jsonAbout
A task with subtasks on a connector tree, progress, priority and status.
Live component. Click, hover, and type to try it.
npx shadcn@latest add https://pinui.xyz/r/task-card.jsonA task with subtasks on a connector tree, progress, priority and status.
"use client";
import { useCallback, useEffect, useId, useLayoutEffect, useRef, useState, type KeyboardEvent as ReactKeyboardEvent } from "react";
import { animate, AnimatePresence, motion, useReducedMotion, type Transition } from "motion/react";
import "./task-card.css";
/**
* Task Card — a task with its subtasks, progress, priority, status and people.
*
* The subtasks hang off one connector tree: a trunk that curves into the last
* row and a branch to every checkbox, drawn as a single SVG whose strokes are
* snapped to whole device pixels, so at 125% or 150% display scaling no
* segment paints heavier than another. Ticking a subtask fills its ring on a
* spring and draws the tick; the progress pill counts up, its bar fills, and
* its icon turns green when everything is done. Status follows along — all
* done sets Done, reopening one puts it back In Progress.
*
* Priority and Status are coloured pills that open a small menu; picking an
* option slides the label out and the next one in while the pill's width
* follows. The ⋯ menu marks everything complete or resets the subtasks. Menus
* take the arrow keys and Escape, and close on a press outside.
*/
type Tone = "red" | "orange" | "blue" | "gray" | "amber" | "violet" | "green";
type Option = { name: string; tone: Tone };
export type TaskCardSubtask = { label: string; done: boolean };
export type TaskCardPerson = { name: string; avatar?: string; color?: string };
export type TaskCardProps = {
theme?: "light" | "dark";
title?: string;
subtasks?: TaskCardSubtask[];
priority?: string;
status?: string;
people?: TaskCardPerson[];
/** Fired whenever anything on the card changes. */
onChange?: (state: { subtasks: TaskCardSubtask[]; priority: string; status: string }) => void;
};
const PRIORITY: Option[] = [
{ name: "Urgent", tone: "red" },
{ name: "High", tone: "orange" },
{ name: "Medium", tone: "blue" },
{ name: "Low", tone: "gray" },
];
const STATUS: Option[] = [
{ name: "To Do", tone: "gray" },
{ name: "In Progress", tone: "amber" },
{ name: "In Review", tone: "violet" },
{ name: "Done", tone: "green" },
];
const DEFAULT_SUBTASKS: TaskCardSubtask[] = [
{ label: "Design Tokens", done: true },
{ label: "Color System", done: true },
{ label: "Type System", done: true },
{ label: "Documentation", done: false },
];
const avatar = (seed: string, bg: string) =>
`https://api.dicebear.com/9.x/avataaars/svg?seed=${encodeURIComponent(seed)}&backgroundColor=${bg}`;
const DEFAULT_PEOPLE: TaskCardPerson[] = [
{ name: "Chloe", color: "#b6e3f4", avatar: avatar("Chloe-Felix", "b6e3f4") },
{ name: "Anna", color: "#d1d4f9", avatar: avatar("Anna-Luna", "d1d4f9") },
{ name: "Ramesh", color: "#ffd5dc", avatar: avatar("Ramesh-Leo", "ffd5dc") },
];
const SPRING: Transition = { type: "spring", stiffness: 500, damping: 36 };
const SOFT: Transition = { type: "spring", stiffness: 260, damping: 30 };
const EASE_OUT = [0.22, 1, 0.36, 1] as const;
/* checkbox and row geometry, shared with the tree so each branch lands exactly on its ring */
const CHECK = { size: 18, view: 20, r: 8.9, stroke: 1.4 };
const ROW = { x: 22, pad: 2, h: 36 };
const FILL_R = 9.6;
const RING_EDGE = ROW.x + ROW.pad + CHECK.size / 2 - (CHECK.r + CHECK.stroke / 2) * (CHECK.size / CHECK.view);
/* branches end half a pixel under the ring's stroke: the ring paints on top, so the join is seamless */
const TREE = { top: 10, radius: 8, reach: RING_EDGE + 0.5 };
/* ------------------------------------------------------------------ */
function Check({ done, delay, reduced }: { done: boolean; delay: number; reduced: boolean | null }) {
return (
<svg viewBox={`0 0 ${CHECK.view} ${CHECK.view}`} width={CHECK.size} height={CHECK.size} className="ptask__check" aria-hidden>
<circle className="ptask__ring" cx="10" cy="10" r={CHECK.r} fill="none" strokeWidth={CHECK.stroke} />
<motion.circle
className="ptask__fill"
cx="10"
cy="10"
initial={{ r: 0 }}
animate={{ r: done ? FILL_R : 0 }}
transition={reduced ? { duration: 0 } : done ? { ...SPRING, delay } : { duration: 0.18, ease: "easeIn", delay: 0.05 }}
/>
<motion.path
className="ptask__tick"
d="M6.3 10.2l2.45 2.45 5-5.1"
fill="none"
strokeWidth="1.9"
strokeLinecap="round"
strokeLinejoin="round"
initial={{ pathLength: 0 }}
animate={{ pathLength: done ? 1 : 0 }}
transition={reduced ? { duration: 0 } : done ? { duration: 0.26, ease: "easeOut", delay: delay + 0.08 } : { duration: 0.12, ease: "easeIn" }}
/>
</svg>
);
}
/** A pill that opens a menu of options; its label slides over and its width follows. */
function PillSelect({
label,
value,
options,
open,
onOpen,
onClose,
onPick,
reduced,
}: {
label: string;
value: string;
options: Option[];
open: boolean;
onOpen: () => void;
onClose: (restore?: boolean) => void;
onPick: (name: string) => void;
reduced: boolean | null;
}) {
const tone = options.find((o) => o.name === value)?.tone ?? "gray";
const menuRef = useRef<HTMLDivElement>(null);
const triggerRef = useRef<HTMLButtonElement>(null);
useEffect(() => {
if (!open) return;
const items = Array.from(menuRef.current?.querySelectorAll<HTMLButtonElement>("[role=menuitemradio]") ?? []);
(items.find((i) => i.getAttribute("aria-checked") === "true") ?? items[0])?.focus({ preventScroll: true });
}, [open]);
const onMenuKey = (e: ReactKeyboardEvent) => {
const step = ({ ArrowDown: 1, ArrowUp: -1 } as Record<string, number>)[e.key];
if (!step) return;
e.preventDefault();
const items = Array.from(menuRef.current?.querySelectorAll<HTMLButtonElement>("[role=menuitemradio]") ?? []);
const i = items.indexOf(document.activeElement as HTMLButtonElement);
items[(i + step + items.length) % items.length]?.focus();
};
return (
<div className="ptask__dd" data-dd>
<motion.button
ref={triggerRef}
type="button"
className="ptask__pill"
data-tone={tone}
aria-haspopup="menu"
aria-expanded={open}
aria-label={`${label}: ${value}`}
onClick={() => (open ? onClose() : onOpen())}
layout={!reduced}
transition={SPRING}
>
<span className="ptask__pillLabel">
<AnimatePresence mode="popLayout" initial={false}>
<motion.span
key={value}
initial={reduced ? false : { y: 6, opacity: 0 }}
animate={{ y: 0, opacity: 1 }}
exit={reduced ? { opacity: 0 } : { y: -6, opacity: 0, transition: { duration: 0.1, ease: "easeIn" } }}
transition={SPRING}
>
{value}
</motion.span>
</AnimatePresence>
</span>
<motion.svg
viewBox="0 0 24 24"
className="ptask__chev"
fill="none"
stroke="currentColor"
strokeWidth="2.4"
strokeLinecap="round"
strokeLinejoin="round"
aria-hidden
layout={!reduced ? "position" : false}
animate={{ rotate: open ? 180 : 0 }}
transition={SPRING}
>
<path d="m6 9 6 6 6-6" />
</motion.svg>
</motion.button>
<AnimatePresence>
{open && (
<motion.div
ref={menuRef}
className="ptask__menu"
role="menu"
aria-label={label}
onKeyDown={onMenuKey}
initial={reduced ? { opacity: 0 } : { opacity: 0, scale: 0.96, y: -4 }}
animate={{ opacity: 1, scale: 1, y: 0, transition: { ...SPRING, opacity: { duration: 0.14, ease: "easeOut" } } }}
exit={reduced ? { opacity: 0 } : { opacity: 0, scale: 0.98, y: -2, transition: { duration: 0.1, ease: "easeIn" } }}
>
{options.map((o) => (
<button
key={o.name}
type="button"
role="menuitemradio"
aria-checked={o.name === value}
className="ptask__item"
data-tone={o.tone}
onClick={() => {
onPick(o.name);
onClose(true);
triggerRef.current?.focus({ preventScroll: true });
}}
>
<span className="ptask__dot" />
<span className="ptask__itemName">{o.name}</span>
<svg viewBox="0 0 24 24" className="ptask__tickmark" data-on={o.name === value || undefined} fill="none" stroke="currentColor" strokeWidth="2.4" strokeLinecap="round" strokeLinejoin="round" aria-hidden>
<path d="m5 12.5 4.5 4.5L19 7.5" />
</svg>
</button>
))}
</motion.div>
)}
</AnimatePresence>
</div>
);
}
/* ------------------------------------------------------------------ */
export default function TaskCard({
theme = "light",
title = "Design System",
subtasks = DEFAULT_SUBTASKS,
priority: initialPriority = "Urgent",
status: initialStatus = "In Progress",
people = DEFAULT_PEOPLE,
onChange,
}: TaskCardProps) {
const reduced = useReducedMotion();
const uid = useId();
const [tasks, setTasks] = useState(() => subtasks.map((t) => ({ ...t })));
const [priority, setPriority] = useState(initialPriority);
const [status, setStatus] = useState(initialStatus);
const [openKey, setOpenKey] = useState<"more" | "priority" | "status" | null>(null);
const [failed, setFailed] = useState<Set<number>>(() => new Set());
/* the counters write their digits straight to the DOM: a count-up never re-renders the card */
const shownRef = useRef({ done: 0, pct: 0 });
const doneRef = useRef<HTMLSpanElement>(null);
const pctRef = useRef<HTMLSpanElement>(null);
const first = useRef(true);
const rootRef = useRef<HTMLDivElement>(null);
const treeRef = useRef<SVGSVGElement>(null);
const moreRef = useRef<HTMLButtonElement>(null);
const moreMenuRef = useRef<HTMLDivElement>(null);
const [tree, setTree] = useState<{ trunk: string; branches: string[]; w: number } | null>(null);
const onChangeRef = useRef(onChange);
onChangeRef.current = onChange;
const total = tasks.length;
const done = tasks.filter((t) => t.done).length;
const pct = total ? Math.round((done / total) * 100) : 0;
const allDone = total > 0 && done === total;
/* the counters roll to their new values */
useEffect(() => {
const delay = first.current ? 0.25 : 0;
first.current = false;
const opts = { duration: reduced ? 0 : 0.45, delay: reduced ? 0 : delay, ease: EASE_OUT };
const write = (el: HTMLSpanElement | null, v: number) => {
const t = String(Math.round(v));
if (el && el.textContent !== t) el.textContent = t;
};
const a = animate(shownRef.current.done, done, {
...opts,
onUpdate: (v) => write(doneRef.current, (shownRef.current.done = v)),
});
const b = animate(shownRef.current.pct, pct, {
...opts,
onUpdate: (v) => write(pctRef.current, (shownRef.current.pct = v)),
});
return () => {
a.stop();
b.stop();
};
}, [done, pct, reduced]);
useEffect(() => {
onChangeRef.current?.({ subtasks: tasks, priority, status });
}, [tasks, priority, status]);
/* status follows completion: all done → Done, reopened → back to In Progress */
const commitTasks = useCallback(
(next: TaskCardSubtask[]) => {
setTasks(next);
const all = next.every((t) => t.done);
if (all) setStatus("Done");
else setStatus((s) => (s === "Done" ? "In Progress" : s));
},
[],
);
/* the tree, snapped to whole device pixels so every segment draws at the same weight.
Its shape depends only on how many rows there are, so ticking a box never re-lays it */
const rows = tasks.length;
const layoutTree = useCallback(() => {
const svg = treeRef.current;
if (!svg) return;
const dpr = window.devicePixelRatio || 1;
const k = Math.max(1, Math.round(dpr));
const w = k / dpr;
const o = svg.getBoundingClientRect();
const crisp = (pos: number, origin: number) => (Math.round((origin + pos) * dpr - k / 2) + k / 2) / dpr - origin;
const x = crisp(0.5, o.left);
const ys = Array.from({ length: rows }, (_, i) => crisp(TREE.top + ROW.h * i + ROW.h / 2, o.top));
const yl = ys[ys.length - 1] ?? 0;
const r = TREE.radius;
const next = {
trunk: `M${x} 0V${yl - r}A${r} ${r} 0 0 0 ${x + r} ${yl}H${TREE.reach}`,
branches: ys.slice(0, -1).map((y) => `M${x} ${y}H${TREE.reach}`),
w,
};
/* only commit when a path actually moved */
setTree((prev) =>
prev && prev.w === next.w && prev.trunk === next.trunk && prev.branches.join() === next.branches.join() ? prev : next,
);
}, [rows]);
useLayoutEffect(() => {
layoutTree();
let frame = 0;
const ro = new ResizeObserver(() => {
cancelAnimationFrame(frame);
frame = requestAnimationFrame(layoutTree);
});
if (rootRef.current) ro.observe(rootRef.current);
addEventListener("resize", layoutTree);
document.fonts?.ready.then(() => layoutTree());
let mq: MediaQueryList | null = null;
const watch = () => {
mq = matchMedia(`(resolution: ${window.devicePixelRatio}dppx)`);
mq.addEventListener("change", onScale, { once: true });
};
const onScale = () => {
layoutTree();
watch();
};
watch();
/* the card slides in; place the tree again where it lands */
const t = setTimeout(layoutTree, 700);
return () => {
ro.disconnect();
cancelAnimationFrame(frame);
removeEventListener("resize", layoutTree);
mq?.removeEventListener("change", onScale);
clearTimeout(t);
};
}, [layoutTree]);
/* menus close on a press outside or Escape */
useEffect(() => {
if (!openKey) return;
const away = (e: PointerEvent) => {
const t = e.target as Element;
if (!rootRef.current?.contains(t) || !t.closest?.("[data-dd]")) setOpenKey(null);
};
const esc = (e: KeyboardEvent) => {
if (e.key !== "Escape") return;
setOpenKey(null);
if (openKey === "more") moreRef.current?.focus({ preventScroll: true });
};
document.addEventListener("pointerdown", away);
document.addEventListener("keydown", esc);
return () => {
document.removeEventListener("pointerdown", away);
document.removeEventListener("keydown", esc);
};
}, [openKey]);
useEffect(() => {
if (openKey === "more") moreMenuRef.current?.querySelector<HTMLButtonElement>("button")?.focus({ preventScroll: true });
}, [openKey]);
const enter = (i: number) => ({
initial: reduced ? false : ({ opacity: 0, y: 5 } as const),
animate: { opacity: 1, y: 0 },
transition: { ...SOFT, opacity: { duration: 0.35, ease: EASE_OUT, delay: 0.08 + i * 0.035 }, delay: 0.08 + i * 0.035 },
});
const moreKey = (e: ReactKeyboardEvent) => {
const step = ({ ArrowDown: 1, ArrowUp: -1 } as Record<string, number>)[e.key];
if (!step) return;
e.preventDefault();
const items = Array.from(moreMenuRef.current?.querySelectorAll<HTMLButtonElement>("button") ?? []);
const i = items.indexOf(document.activeElement as HTMLButtonElement);
items[(i + step + items.length) % items.length]?.focus();
};
return (
<div ref={rootRef} className="ptask" data-theme={theme}>
<motion.section
className="ptask__card"
aria-label={title}
initial={reduced ? false : { opacity: 0, y: 10 }}
animate={{ opacity: 1, y: 0 }}
transition={{ ...SOFT, opacity: { duration: 0.35, ease: EASE_OUT } }}
>
{/* header */}
<motion.header className="ptask__head" {...enter(0)}>
<div className="ptask__brand">
<span className="ptask__logo" aria-hidden>
<svg viewBox="0 0 24 24" fill="none" stroke="currentColor" strokeWidth="1.7" strokeLinejoin="round">
<path d="M12 2.6l8.15 4.7v9.4L12 21.4l-8.15-4.7V7.3z" />
<circle cx="12" cy="12" r="3.4" />
</svg>
</span>
<h3 className="ptask__title">{title}</h3>
</div>
<div className="ptask__dd" data-dd>
<button
ref={moreRef}
type="button"
className="ptask__icon"
aria-haspopup="menu"
aria-expanded={openKey === "more"}
aria-label="More options"
onClick={() => setOpenKey((k) => (k === "more" ? null : "more"))}
>
<svg viewBox="0 0 24 24" fill="currentColor" aria-hidden>
<circle cx="5" cy="12" r="1.8" />
<circle cx="12" cy="12" r="1.8" />
<circle cx="19" cy="12" r="1.8" />
</svg>
</button>
<AnimatePresence>
{openKey === "more" && (
<motion.div
ref={moreMenuRef}
className="ptask__menu ptask__menu--right"
role="menu"
aria-label="More options"
onKeyDown={moreKey}
initial={reduced ? { opacity: 0 } : { opacity: 0, scale: 0.96, y: -4 }}
animate={{ opacity: 1, scale: 1, y: 0, transition: { ...SPRING, opacity: { duration: 0.14, ease: "easeOut" } } }}
exit={reduced ? { opacity: 0 } : { opacity: 0, scale: 0.98, y: -2, transition: { duration: 0.1, ease: "easeIn" } }}
>
<button
type="button"
role="menuitem"
className="ptask__item"
onClick={() => {
commitTasks(tasks.map((t) => ({ ...t, done: true })));
setOpenKey(null);
moreRef.current?.focus({ preventScroll: true });
}}
>
<svg viewBox="0 0 24 24" className="ptask__itemIcon" fill="none" stroke="currentColor" strokeWidth="2" strokeLinecap="round" strokeLinejoin="round" aria-hidden>
<circle cx="12" cy="12" r="9" />
<path d="m8.5 12.5 2.5 2.5 4.5-5" />
</svg>
Mark all complete
</button>
<button
type="button"
role="menuitem"
className="ptask__item"
onClick={() => {
commitTasks(subtasks.map((t) => ({ ...t })));
setOpenKey(null);
moreRef.current?.focus({ preventScroll: true });
}}
>
<svg viewBox="0 0 24 24" className="ptask__itemIcon" fill="none" stroke="currentColor" strokeWidth="2" strokeLinecap="round" strokeLinejoin="round" aria-hidden>
<path d="M3 12a9 9 0 1 0 9-9 9.75 9.75 0 0 0-6.74 2.74L3 8" />
<path d="M3 3v5h5" />
</svg>
Reset subtasks
</button>
</motion.div>
)}
</AnimatePresence>
</div>
</motion.header>
{/* progress */}
<motion.div className="ptask__progressRow" {...enter(1)}>
<div
className="ptask__progress"
role="progressbar"
aria-label="Subtask progress"
aria-valuemin={0}
aria-valuemax={100}
aria-valuenow={pct}
>
<svg viewBox="0 0 24 24" className="ptask__progressIcon" data-done={allDone || undefined} fill="none" stroke="currentColor" strokeWidth="1.7" strokeLinecap="round" strokeLinejoin="round" aria-hidden>
<circle cx="12" cy="12" r="9.2" />
<path d="m8.4 12.3 2.5 2.5 4.8-5" />
</svg>
<span className="ptask__count">
<span ref={doneRef}>0</span> of {total}
</span>
<span className="ptask__track">
<motion.span
className="ptask__bar"
initial={{ width: "0%" }}
animate={{ width: `${pct}%` }}
transition={reduced ? { duration: 0 } : { ...SOFT, delay: first.current ? 0.25 : 0 }}
/>
</span>
<span className="ptask__pct">
<span ref={pctRef}>0</span>%
</span>
</div>
</motion.div>
{/* subtasks, hung off one connector tree */}
<ul className="ptask__tasks" aria-label="Subtasks">
<svg
ref={treeRef}
className="ptask__tree"
width={TREE.reach}
height={TREE.top + ROW.h * tasks.length}
aria-hidden
>
{tree && (
<>
<motion.path
className="ptask__line"
d={tree.trunk}
strokeWidth={tree.w}
initial={reduced ? false : { pathLength: 0 }}
animate={{ pathLength: 1 }}
transition={{ duration: 0.5, ease: EASE_OUT, delay: 0.14 }}
/>
{tree.branches.map((d, i) => (
<motion.path
key={i}
className="ptask__line"
d={d}
strokeWidth={tree.w}
initial={reduced ? false : { pathLength: 0 }}
animate={{ pathLength: 1 }}
transition={{ duration: 0.25, ease: EASE_OUT, delay: 0.22 + i * 0.06 }}
/>
))}
</>
)}
</svg>
{tasks.map((t, i) => (
<li key={`${uid}-${i}`} className="ptask__task">
<motion.button
type="button"
role="checkbox"
aria-checked={t.done}
className="ptask__row"
style={{ left: ROW.x, paddingLeft: ROW.pad }}
onClick={() => commitTasks(tasks.map((x, j) => (j === i ? { ...x, done: !x.done } : x)))}
{...enter(2 + i)}
>
<Check done={t.done} delay={first.current ? 0.3 + i * 0.05 : 0} reduced={reduced} />
<span className="ptask__label">{t.label}</span>
</motion.button>
</li>
))}
</ul>
{/* properties */}
<div className="ptask__props">
<motion.div className="ptask__prop" {...enter(2 + tasks.length)}>
<span className="ptask__propName">
<svg viewBox="0 0 24 24" fill="none" stroke="currentColor" strokeWidth="1.6" strokeLinecap="round" strokeLinejoin="round" aria-hidden>
<path className="ptask__iconFill" d="M4 15s1-1 4-1 5 2 8 2 4-1 4-1V3s-1 1-4 1-5-2-8-2-4 1-4 1z" />
<path d="M4 22v-7" />
</svg>
Priority
</span>
<PillSelect
label="Priority"
value={priority}
options={PRIORITY}
open={openKey === "priority"}
onOpen={() => setOpenKey("priority")}
onClose={() => setOpenKey(null)}
onPick={setPriority}
reduced={reduced}
/>
</motion.div>
<motion.div className="ptask__prop" {...enter(3 + tasks.length)}>
<span className="ptask__propName">
<svg viewBox="0 0 24 24" fill="none" stroke="currentColor" strokeWidth="1.6" strokeLinecap="round" strokeLinejoin="round" aria-hidden>
<path d="M5 22h14M5 2h14" />
<path className="ptask__iconFill" d="M17 22v-4.17a2 2 0 0 0-.59-1.42L12 12l-4.41 4.41A2 2 0 0 0 7 17.83V22" />
<path className="ptask__iconFill" d="M7 2v4.17a2 2 0 0 0 .59 1.42L12 12l4.41-4.41A2 2 0 0 0 17 6.17V2" />
</svg>
Status
</span>
<PillSelect
label="Status"
value={status}
options={STATUS}
open={openKey === "status"}
onOpen={() => setOpenKey("status")}
onClose={() => setOpenKey(null)}
onPick={setStatus}
reduced={reduced}
/>
</motion.div>
</div>
{/* assignees */}
<ul className="ptask__people" aria-label="Assignees">
{people.map((p, i) => (
<motion.li key={p.name} className="ptask__person" {...enter(4 + tasks.length + i)}>
<span className="ptask__avatar" style={{ background: p.color ?? "#e4e4e7" }}>
{p.avatar && !failed.has(i) ? (
// eslint-disable-next-line @next/next/no-img-element
<img alt="" width={27} height={27} src={p.avatar} onError={() => setFailed((s) => new Set(s).add(i))} />
) : (
p.name[0]
)}
</span>
{p.name}
</motion.li>
))}
</ul>
</motion.section>
</div>
);
}
