Level MeterNew

"use client";

import { cva } from "class-variance-authority";
import type { VariantProps } from "class-variance-authority";
import {
  createContext,
  useCallback,
  useContext,
  useEffect,
  useEffectEvent,
  useImperativeHandle,
  useMemo,
  useRef,
  useState,
} from "react";
import type { ComponentProps, CSSProperties, Ref, RefObject } from "react";

import { ClipIndicator } from "@/components/ui/clip-indicator";
import type { ClipIndicatorProps } from "@/components/ui/clip-indicator";
import { DbReadout, readChannel } from "@/components/ui/db-readout";
import type { DbReadoutProps } from "@/components/ui/db-readout";
import { DbScale } from "@/components/ui/db-scale";
import type { DbScaleProps } from "@/components/ui/db-scale";
import { useAudioConfig } from "@/hooks/use-audio-config";
import type { AudioSize } from "@/hooks/use-audio-config";
import { useFrameSource } from "@/hooks/use-frame-source";
import { useReducedMotion } from "@/hooks/use-reduced-motion";
import { useVisibility } from "@/hooks/use-visibility";
import { createBallistics, resolveBallistics } from "@/lib/audio/ballistics";
import type { Ballistics, BallisticsInput } from "@/lib/audio/ballistics";
import {
  DEFAULT_MAX_DB,
  DEFAULT_MIN_DB,
  formatDb,
  SILENCE_DB,
} from "@/lib/audio/decibels";
import { createFrameTask, createPainterClock } from "@/lib/audio/frame-loop";
import { createFrameEmitter } from "@/lib/audio/frame-source";
import { resolveTaper } from "@/lib/audio/taper";
import type { TaperInput } from "@/lib/audio/taper";
import type {
  ChannelLevel,
  FrameSource,
  MeterFrame,
  MeterZone,
  Orientation,
  Taper,
} from "@/lib/audio/types";
import {
  CLIP_HOLD_MS,
  CLIP_THRESHOLD_DB,
  DEFAULT_ZONES,
  zoneForDb,
} from "@/lib/audio/zones";
import { cn } from "@/lib/utils";

const ARIA_INTERVAL_MS = 250;
const REDUCED_MOTION_INTERVAL_MS = 250;
const DEFAULT_SEGMENTS = 24;
const POSITION_EPSILON = 0.0005;
/**
 * A meter this close to its input has nothing visible left to animate (about
 * 0.06 dB on the default range, under a pixel on any meter), so it sleeps.
 */
const SETTLE_EPSILON = 0.001;

export type LevelMeterVariant = "solid" | "segmented" | "gradient";

export interface LevelMeterActions {
  /** Paint a frame directly, for callers that own their own frame loop. */
  paint: (frame: MeterFrame) => void;
  /** Drop the level and the peak hold to silence. */
  reset: () => void;
}

interface LevelMeterContextValue {
  orientation: Orientation;
  variant: LevelMeterVariant;
  minDb: number;
  maxDb: number;
  taper: Taper;
  frames: FrameSource<MeterFrame>;
  /** The declarative levels, when the meter has values instead of a source. */
  declared: MeterFrame | null;
  registerChannel: (index: number, element: HTMLElement | null) => void;
}

const LevelMeterContext = createContext<LevelMeterContextValue | null>(null);

const useLevelMeter = (part: string) => {
  const context = useContext(LevelMeterContext);
  if (!context) {
    throw new Error(`${part} must be used inside LevelMeter.`);
  }
  return context;
};

/**
 * Zones in rising order, as a new array. An insertion rather than the ES2023
 * sorted-copy method, which projects compiling against ES2022 lack; a meter
 * has a handful of zones.
 */
const byFromDb = (zones: MeterZone[]): MeterZone[] => {
  const sorted: MeterZone[] = [];
  for (const zone of zones) {
    const index = sorted.findIndex((other) => other.fromDb > zone.fromDb);
    if (index === -1) {
      sorted.push(zone);
    } else {
      sorted.splice(index, 0, zone);
    }
  }
  return sorted;
};

const buildZoneFill = (
  zones: MeterZone[],
  taper: Taper,
  orientation: Orientation,
  variant: LevelMeterVariant
) => {
  const direction = orientation === "horizontal" ? "to right" : "to top";
  const sorted = byFromDb(zones);
  // Rounded so the server and the browser print the same stops.
  const starts = sorted.map((zone) =>
    Number((taper.toPosition(zone.fromDb) * 100).toFixed(3))
  );

  if (variant === "gradient") {
    const stops = sorted.map(
      (zone, index) => `var(--meter-${zone.zone}) ${starts[index] ?? 0}%`
    );
    const last = sorted.at(-1);
    return `linear-gradient(${direction}, ${stops.join(", ")}, var(--meter-${last?.zone ?? "ok"}) 100%)`;
  }

  const stops = sorted.map((zone, index) => {
    const start = starts[index] ?? 0;
    const end = starts[index + 1] ?? 100;
    return `var(--meter-${zone.zone}) ${start}% ${end}%`;
  });
  return `linear-gradient(${direction}, ${stops.join(", ")})`;
};

const buildSegmentMask = (orientation: Orientation, segments: number) => {
  const direction = orientation === "horizontal" ? "to right" : "to top";
  const size = `calc(100% / ${segments})`;
  return `repeating-linear-gradient(${direction}, black 0 calc(${size} - 2px), transparent calc(${size} - 2px) ${size})`;
};

const serializeLevels = (
  channels: ChannelLevel[] | undefined,
  peakDb: number | undefined,
  rmsDb: number | undefined
): string => {
  if (channels) {
    return channels.map((level) => `${level.peakDb}:${level.rmsDb}`).join("|");
  }
  if (peakDb === undefined && rmsDb === undefined) {
    return "";
  }
  return `${peakDb ?? SILENCE_DB}:${rmsDb}`;
};

const parseNumber = (text: string | undefined): number | undefined => {
  const value = Number(text);
  return Number.isNaN(value) ? undefined : value;
};

const parseLevels = (key: string): MeterFrame | null => {
  if (key === "") {
    return null;
  }
  return {
    channels: key.split("|").map((entry) => {
      const [peak, rms] = entry.split(":");
      return {
        peakDb: parseNumber(peak) ?? SILENCE_DB,
        rmsDb: parseNumber(rms),
      };
    }),
  };
};

interface ChannelState {
  element: HTMLElement;
  peak: Ballistics;
  rms: Ballistics;
  level: number;
  rmsLevel: number;
  hold: number;
  zone: string;
  /** Null until first painted, so a new painter always writes it. */
  active: boolean | null;
}

/** Handed to the painter when it changes, so it never rebuilds the painter. */
interface MeterScale {
  maxDb: number;
  minDb: number;
  taper: Taper;
  zones: MeterZone[];
}

interface PainterOptions {
  ballistics: BallisticsInput;
  channels: Map<number, HTMLElement>;
  latest: RefObject<MeterFrame | null>;
  reducedMotion: boolean;
  root: RefObject<HTMLElement | null>;
  scale: MeterScale;
  visible: RefObject<boolean>;
}

interface MeterPainter {
  /** Paints one frame. Returns true while the meter needs another. */
  paint: (frameMs: number) => boolean;
  /** A new range, taper or zones, used from the next frame. */
  setScale: (scale: MeterScale) => void;
}

const silentLevel: ChannelLevel = { peakDb: SILENCE_DB };

const noop = () => {
  // Nothing to wake before the painter starts.
};

const writePosition = (
  element: HTMLElement,
  property: string,
  previous: number,
  next: number
) => {
  if (Math.abs(previous - next) > POSITION_EPSILON) {
    element.style.setProperty(property, next.toFixed(4));
    return next;
  }
  return previous;
};

interface ChannelPaint {
  /** The smoothed peak this frame, in dBFS. */
  db: number;
  /** Level, RMS and hold have all reached the input: nothing left to animate. */
  settled: boolean;
}

/**
 * Paints a meter's channels outside React: steps ballistics, writes CSS
 * variables and data attributes, and throttles ARIA updates. Returns true
 * while it needs another frame, so a meter that has settled, or is off
 * screen, stops costing frames until something wakes it.
 */
const createMeterPainter = (options: PainterOptions): MeterPainter => {
  const ballisticsOptions: BallisticsInput = options.reducedMotion
    ? "instant"
    : options.ballistics;
  const states = new Map<number, ChannelState>();
  const clock = createPainterClock();
  let { scale } = options;
  let clipUntil = 0;
  // Null until first painted: a painter rebuilt mid-clip must still clear
  // the attribute the previous one left.
  let clippingShown: boolean | null = null;
  let lastAriaMs = Number.NEGATIVE_INFINITY;
  let ariaShown: string | null = null;
  let rootZoneShown: string | null = null;
  let lastPaintMs = Number.NEGATIVE_INFINITY;

  const stateFor = (index: number, element: HTMLElement) => {
    const existing = states.get(index);
    if (existing && existing.element === element) {
      return existing;
    }
    const created: ChannelState = {
      active: null,
      element,
      hold: -1,
      level: -1,
      peak: createBallistics(ballisticsOptions),
      rms: createBallistics({
        ...resolveBallistics(ballisticsOptions),
        peakHoldMs: 0,
      }),
      rmsLevel: -1,
      zone: "",
    };
    states.set(index, created);
    return created;
  };

  const paintChannel = (
    index: number,
    element: HTMLElement,
    input: ChannelLevel,
    nowMs: number
  ): ChannelPaint => {
    const state = stateFor(index, element);
    const inputRmsDb = input.rmsDb ?? input.peakDb;
    const peak = state.peak.step(input.peakDb, nowMs);
    const rms = state.rms.step(inputRmsDb, nowMs);
    const { taper } = scale;
    const level = taper.toPosition(peak.db);
    const rmsLevel = taper.toPosition(rms.db);
    const hold = taper.toPosition(peak.holdDb);
    state.level = writePosition(element, "--meter-level", state.level, level);
    state.rmsLevel = writePosition(
      element,
      "--meter-rms",
      state.rmsLevel,
      rmsLevel
    );
    state.hold = writePosition(element, "--meter-hold", state.hold, hold);

    const zone = zoneForDb(peak.db, scale.zones);
    if (zone !== state.zone) {
      state.zone = zone;
      element.dataset.zone = zone;
    }
    const active = state.level > 0;
    if (active !== state.active) {
      state.active = active;
      element.toggleAttribute("data-active", active);
    }
    const settled =
      Math.abs(level - taper.toPosition(input.peakDb)) <= SETTLE_EPSILON &&
      Math.abs(rmsLevel - taper.toPosition(inputRmsDb)) <= SETTLE_EPSILON &&
      Math.abs(hold - level) <= SETTLE_EPSILON;
    return { db: peak.db, settled };
  };

  const paintRoot = (
    root: HTMLElement,
    loudest: number,
    nowMs: number,
    settled: boolean
  ) => {
    const clipping = nowMs < clipUntil;
    if (clipping !== clippingShown) {
      clippingShown = clipping;
      root.toggleAttribute("data-clipping", clipping);
    }
    const text = formatDb(loudest, { floorDb: scale.minDb });
    const zone = zoneForDb(loudest, scale.zones);
    if (text === ariaShown && zone === rootZoneShown) {
      return;
    }
    // Throttled while the level moves; a settled level is written at once,
    // so the value a screen reader finds is never a stale one.
    if (!settled && nowMs - lastAriaMs < ARIA_INTERVAL_MS) {
      return;
    }
    lastAriaMs = nowMs;
    ariaShown = text;
    rootZoneShown = zone;
    const clamped = Math.min(scale.maxDb, Math.max(scale.minDb, loudest));
    root.setAttribute("aria-valuenow", clamped.toFixed(1));
    root.setAttribute("aria-valuetext", text);
    root.dataset.zone = zone;
  };

  const paint = (frameMs: number): boolean => {
    // Hidden: sleep. Coming back into view wakes the painter.
    if (!options.visible.current) {
      return false;
    }
    const nowMs = clock(frameMs);
    if (
      options.reducedMotion &&
      nowMs - lastPaintMs < REDUCED_MOTION_INTERVAL_MS
    ) {
      return true;
    }
    lastPaintMs = nowMs;
    const frame = options.latest.current;
    let loudest = SILENCE_DB;
    let settled = true;
    let inputClipping = false;
    for (const [index, element] of options.channels) {
      const input = frame?.channels[index] ?? silentLevel;
      if (input.peakDb >= CLIP_THRESHOLD_DB) {
        clipUntil = nowMs + CLIP_HOLD_MS;
        inputClipping = true;
      }
      const painted = paintChannel(index, element, input, nowMs);
      loudest = Math.max(loudest, painted.db);
      settled &&= painted.settled;
    }
    const root = options.root.current;
    if (root) {
      paintRoot(root, loudest, nowMs, settled);
    }
    // A clip light counting down after the input dropped needs the frames
    // that turn it off; one held by a still-clipping input does not.
    const releasingClip = nowMs < clipUntil && !inputClipping;
    return !settled || releasingClip;
  };

  return {
    paint,
    setScale: (next) => {
      scale = next;
    },
  };
};

export const LevelMeterChannels = ({
  className,
  ...props
}: ComponentProps<"div">) => {
  const { orientation } = useLevelMeter("LevelMeterChannels");
  return (
    <div
      className={cn(
        "relative flex min-h-0 min-w-0 flex-1 gap-(--meter-gap)",
        orientation === "horizontal" ? "flex-col" : "h-full flex-row",
        className
      )}
      data-orientation={orientation}
      data-slot="level-meter-channels"
      {...props}
    />
  );
};

export interface LevelMeterChannelProps extends ComponentProps<"div"> {
  /** Which channel of the frames this track shows. Default 0. */
  index?: number;
}

export const LevelMeterChannel = ({
  index = 0,
  className,
  ref,
  ...props
}: LevelMeterChannelProps) => {
  const { orientation, registerChannel } = useLevelMeter("LevelMeterChannel");

  const setRef = useCallback(
    (node: HTMLDivElement | null) => {
      registerChannel(index, node);
      if (typeof ref === "function") {
        ref(node);
      } else if (ref) {
        ref.current = node;
      }
    },
    [index, ref, registerChannel]
  );

  return (
    <div
      className={cn(
        "flex min-h-0 min-w-0 [--meter-hold:0] [--meter-level:0] [--meter-rms:0]",
        orientation === "horizontal" ? "w-full" : "h-full",
        className
      )}
      data-index={index}
      data-orientation={orientation}
      data-slot="level-meter-channel"
      ref={setRef}
      {...props}
    />
  );
};

export const LevelMeterTrack = ({
  className,
  children,
  ...props
}: ComponentProps<"div">) => {
  const { orientation, variant } = useLevelMeter("LevelMeterTrack");
  const horizontal = orientation === "horizontal";

  return (
    <div
      className={cn(
        "bg-muted relative overflow-hidden rounded-full",
        horizontal
          ? "h-(--meter-thickness) w-full"
          : "h-full w-(--meter-thickness)",
        className
      )}
      data-orientation={orientation}
      data-slot="level-meter-track"
      {...props}
    >
      {variant === "segmented" ? (
        <div
          aria-hidden
          className="absolute inset-0 bg-(image:--meter-fill) mask-(--meter-mask) opacity-20"
          data-slot="level-meter-segments"
        />
      ) : null}
      {children}
    </div>
  );
};

export interface LevelMeterBarProps extends ComponentProps<"div"> {
  /** Which measurement this bar shows. Layer a `rms` and a `peak` bar for a dual meter. Default `peak`. */
  measure?: "peak" | "rms";
}

export const LevelMeterBar = ({
  measure = "peak",
  className,
  ...props
}: LevelMeterBarProps) => {
  const { orientation } = useLevelMeter("LevelMeterBar");
  const horizontal = orientation === "horizontal";

  return (
    <div
      aria-hidden
      className={cn(
        "absolute inset-0 overflow-hidden",
        measure === "rms"
          ? "[--meter-bar-level:var(--meter-rms)]"
          : "[--meter-bar-level:var(--meter-level)]",
        horizontal
          ? "translate-x-[calc((var(--meter-bar-level)_-_1)_*_100%)]"
          : "translate-y-[calc((1_-_var(--meter-bar-level))_*_100%)]",
        className
      )}
      data-measure={measure}
      data-slot="level-meter-bar"
      {...props}
    >
      <div
        className={cn(
          "absolute inset-0 bg-(image:--meter-fill) mask-(--meter-mask)",
          horizontal
            ? "translate-x-[calc((1_-_var(--meter-bar-level))_*_100%)]"
            : "translate-y-[calc((var(--meter-bar-level)_-_1)_*_100%)]"
        )}
        data-slot="level-meter-fill"
      />
    </div>
  );
};

export const LevelMeterHold = ({
  className,
  ...props
}: ComponentProps<"div">) => {
  const { orientation } = useLevelMeter("LevelMeterHold");
  const horizontal = orientation === "horizontal";

  return (
    <div
      aria-hidden
      className={cn(
        "pointer-events-none absolute inset-0 opacity-[calc(var(--meter-hold)_*_50)]",
        horizontal
          ? "translate-x-[calc((var(--meter-hold)_-_1)_*_100%)]"
          : "translate-y-[calc((1_-_var(--meter-hold))_*_100%)]"
      )}
      data-slot="level-meter-hold"
      {...props}
    >
      <div
        className={cn(
          "bg-foreground/80 absolute",
          horizontal ? "inset-y-0 right-0 w-0.5" : "inset-x-0 top-0 h-0.5",
          className
        )}
      />
    </div>
  );
};

export type LevelMeterScaleProps = Omit<
  DbScaleProps,
  "minDb" | "maxDb" | "taper" | "orientation"
>;

export const LevelMeterScale = ({
  className,
  ...props
}: LevelMeterScaleProps) => {
  const { maxDb, minDb, orientation, taper } = useLevelMeter("LevelMeterScale");
  // Horizontal meters reserve space below the tracks for the scale.
  return (
    <DbScale
      className={cn(
        orientation === "horizontal" &&
          "absolute top-[calc(100%+var(--meter-gap))] left-0 h-(--meter-scale-size)",
        className
      )}
      maxDb={maxDb}
      minDb={minDb}
      orientation={orientation}
      taper={taper}
      {...props}
    />
  );
};

export type LevelMeterValueProps = Omit<DbReadoutProps, "source" | "value">;

export const LevelMeterValue = (props: LevelMeterValueProps) => {
  const { declared, frames, minDb } = useLevelMeter("LevelMeterValue");
  // Declarative levels only change on render, so show them as a value. A
  // stream keeps its live readout, which falls to −∞ when it stops.
  const value = declared
    ? readChannel(declared, props.measure ?? "peak", props.channel ?? "max")
    : undefined;
  return (
    <DbReadout
      className="text-muted-foreground text-xs"
      floorDb={minDb}
      source={declared ? null : frames}
      value={value}
      {...props}
    />
  );
};

export type LevelMeterClipProps = Omit<ClipIndicatorProps, "source">;

export const LevelMeterClip = (props: LevelMeterClipProps) => {
  const { frames } = useLevelMeter("LevelMeterClip");
  return <ClipIndicator source={frames} {...props} />;
};

const levelMeterVariants = cva(
  // Animated bars and peak markers must not become the page's scroll anchor.
  "group/level-meter flex gap-2 [--meter-gap:0.25rem] [overflow-anchor:none] data-dimmed:opacity-50",
  {
    defaultVariants: {
      orientation: "horizontal",
      size: "default",
    },
    variants: {
      orientation: {
        horizontal:
          "w-full flex-row items-center [--meter-scale-size:1rem] has-[[data-slot=db-scale]]:pb-[calc(var(--meter-scale-size)+var(--meter-gap))]",
        vertical: "min-h-32 flex-col items-center",
      },
      size: {
        default: "[--meter-thickness:0.5rem]",
        lg: "[--meter-thickness:0.75rem]",
        sm: "[--meter-thickness:0.25rem]",
      },
    },
  }
);

export interface LevelMeterProps
  extends
    ComponentProps<"div">,
    Omit<VariantProps<typeof levelMeterVariants>, "orientation"> {
  /** A meter source; the meter subscribes and paints itself without re-rendering React. */
  source?: FrameSource<MeterFrame> | null;
  /** Mono peak level in dBFS, for declarative use. */
  peakDb?: number;
  /** Mono RMS level in dBFS, for declarative use. */
  rmsDb?: number;
  /** Levels per channel, for declarative multi-channel use. */
  channels?: ChannelLevel[];
  /** Tracks to render before data arrives. Default 1. */
  channelCount?: number;
  /** Bottom of the displayed range. Default −60. */
  minDb?: number;
  /** Top of the displayed range. Default 0. */
  maxDb?: number;
  /** Colour zones. Default ok / warn from −20 / clip from −9. */
  zones?: MeterZone[];
  /** How the meter moves. Default `peak`. */
  ballistics?: BallisticsInput;
  /** Scale law. Default `linear`. */
  taper?: TaperInput;
  orientation?: Orientation;
  /** `segmented` is an LED ladder. Default `solid`. */
  variant?: LevelMeterVariant;
  /** Segments for the `segmented` variant. Default 24. */
  segments?: number;
  actionsRef?: Ref<LevelMeterActions>;
}

interface MeterSettings {
  orientation: Orientation;
  size: AudioSize;
  minDb: number;
  maxDb: number;
  zones: MeterZone[];
  ballistics: BallisticsInput;
  dimmed: boolean;
}

/** Explicit props win over the surrounding mixer or strip. */
const useMeterSettings = (props: Partial<MeterSettings>): MeterSettings => {
  const config = useAudioConfig();
  return {
    ballistics: props.ballistics ?? config.ballistics ?? "peak",
    dimmed: config.dimmed ?? false,
    maxDb: props.maxDb ?? config.maxDb ?? DEFAULT_MAX_DB,
    minDb: props.minDb ?? config.minDb ?? DEFAULT_MIN_DB,
    orientation: props.orientation ?? config.orientation ?? "horizontal",
    size: props.size ?? config.size ?? "default",
    zones: props.zones ?? config.zones ?? DEFAULT_ZONES,
  };
};

export const LevelMeter = ({
  source,
  peakDb,
  rmsDb,
  channels,
  channelCount: channelCountProp,
  minDb: minDbProp,
  maxDb: maxDbProp,
  zones: zonesProp,
  ballistics: ballisticsProp,
  taper = "linear",
  orientation: orientationProp,
  variant = "solid",
  segments = DEFAULT_SEGMENTS,
  size: sizeProp,
  actionsRef,
  className,
  children,
  ref,
  style,
  ...props
}: LevelMeterProps) => {
  const settings = useMeterSettings({
    ballistics: ballisticsProp,
    maxDb: maxDbProp,
    minDb: minDbProp,
    orientation: orientationProp,
    size: sizeProp ?? undefined,
    zones: zonesProp,
  });
  const { maxDb, minDb, orientation, zones } = settings;
  const reducedMotion = useReducedMotion();
  const frames = useMemo(() => createFrameEmitter<MeterFrame>(), []);
  const latestRef = useRef<MeterFrame | null>(null);
  const rootRef = useRef<HTMLDivElement | null>(null);
  const channelsRef = useRef(new Map<number, HTMLElement>());
  // Wakes the painter when something changed. A settled meter sleeps.
  const wakeRef = useRef<() => void>(noop);
  const visibleRef = useVisibility(rootRef, (visible) => {
    if (visible) {
      wakeRef.current();
    }
  });
  const [observedCount, setObservedCount] = useState<number | null>(null);

  const accept = useCallback(
    (frame: MeterFrame) => {
      latestRef.current = frame;
      frames.emit(frame);
      wakeRef.current();
    },
    [frames]
  );

  const acceptAndCount = useCallback(
    (frame: MeterFrame) => {
      accept(frame);
      const count = frame.channels.length;
      if (count > 0) {
        setObservedCount((previous) => (previous === count ? previous : count));
      }
    },
    [accept]
  );

  useFrameSource(source, acceptAndCount);

  const declarativeKey = serializeLevels(channels, peakDb, rmsDb);
  let declaredCount: number | null = null;
  if (channels) {
    declaredCount = channels.length;
  } else if (declarativeKey !== "") {
    declaredCount = 1;
  }
  const channelCount = declaredCount ?? observedCount ?? channelCountProp ?? 1;
  const declared = useMemo(
    () => (source ? null : parseLevels(declarativeKey)),
    [declarativeKey, source]
  );

  useEffect(() => {
    const frame = parseLevels(declarativeKey);
    if (frame) {
      accept(frame);
    }
  }, [accept, declarativeKey]);

  const taperFn = useMemo(
    () => resolveTaper(taper, minDb, maxDb),
    [taper, minDb, maxDb]
  );

  const registerChannel = useCallback(
    (index: number, element: HTMLElement | null) => {
      if (element) {
        channelsRef.current.set(index, element);
      } else {
        channelsRef.current.delete(index);
      }
      wakeRef.current();
    },
    []
  );

  const ballisticsKey = JSON.stringify(
    typeof settings.ballistics === "string"
      ? settings.ballistics
      : resolveBallistics(settings.ballistics)
  );

  // Scale changes (an inline zones array, a new range) reach the painter on
  // its next frame instead of rebuilding it and resetting the ballistics.
  const scale = useMemo<MeterScale>(
    () => ({ maxDb, minDb, taper: taperFn, zones }),
    [maxDb, minDb, taperFn, zones]
  );
  const readScale = useEffectEvent(() => scale);
  const painterRef = useRef<MeterPainter | null>(null);

  useEffect(() => {
    const painter = createMeterPainter({
      ballistics: JSON.parse(ballisticsKey) as BallisticsInput,
      channels: channelsRef.current,
      latest: latestRef,
      reducedMotion,
      root: rootRef,
      scale: readScale(),
      visible: visibleRef,
    });
    const task = createFrameTask(painter.paint);
    painterRef.current = painter;
    wakeRef.current = task.wake;
    return () => {
      painterRef.current = null;
      wakeRef.current = noop;
      task.stop();
    };
  }, [ballisticsKey, reducedMotion, visibleRef]);

  // A new range or zones array reaches the painter, and repaints a meter that
  // had settled.
  useEffect(() => {
    painterRef.current?.setScale(scale);
    wakeRef.current();
  }, [scale]);

  useImperativeHandle(
    actionsRef,
    () => ({
      paint: acceptAndCount,
      reset: () => {
        accept({ channels: [] });
      },
    }),
    [accept, acceptAndCount]
  );

  const zoneFill = useMemo(
    () => buildZoneFill(zones, taperFn, orientation, variant),
    [orientation, taperFn, variant, zones]
  );
  const segmentMask =
    variant === "segmented" ? buildSegmentMask(orientation, segments) : "none";

  const contextValue = useMemo<LevelMeterContextValue>(
    () => ({
      declared,
      frames,
      maxDb,
      minDb,
      orientation,
      registerChannel,
      taper: taperFn,
      variant,
    }),
    [
      declared,
      frames,
      maxDb,
      minDb,
      orientation,
      registerChannel,
      taperFn,
      variant,
    ]
  );

  const setRootRef = useCallback(
    (node: HTMLDivElement | null) => {
      rootRef.current = node;
      if (typeof ref === "function") {
        ref(node);
      } else if (ref) {
        ref.current = node;
      }
    },
    [ref]
  );

  return (
    <LevelMeterContext.Provider value={contextValue}>
      <div
        aria-valuemax={maxDb}
        aria-valuemin={minDb}
        aria-valuenow={minDb}
        className={cn(
          levelMeterVariants({ orientation, size: settings.size }),
          className
        )}
        data-dimmed={settings.dimmed ? "" : undefined}
        data-orientation={orientation}
        data-size={settings.size}
        data-slot="level-meter"
        data-variant={variant}
        ref={setRootRef}
        role="meter"
        style={
          {
            "--meter-fill": zoneFill,
            "--meter-mask": segmentMask,
            ...style,
          } as CSSProperties
        }
        {...props}
      >
        {children ?? (
          <LevelMeterChannels>
            {Array.from({ length: channelCount }, (_, index) => (
              <LevelMeterChannel index={index} key={`channel-${index}`}>
                <LevelMeterTrack>
                  <LevelMeterBar />
                  <LevelMeterHold />
                </LevelMeterTrack>
              </LevelMeterChannel>
            ))}
          </LevelMeterChannels>
        )}
      </div>
    </LevelMeterContext.Provider>
  );
};

export { levelMeterVariants };
