EndpointNew
Live component. Click, hover, and type to try it.
Install
npx shadcn@latest add https://mdxcn.dev/r/endpoint.jsonAbout
One API route. Method and path, a params table, request and response fences.
Live component. Click, hover, and type to try it.
npx shadcn@latest add https://mdxcn.dev/r/endpoint.jsonOne API route. Method and path, a params table, request and response fences.
"use client"
import type { ReactElement, ReactNode } from "react"
import { motion, useReducedMotion } from "motion/react"
import {
childrenOf,
elementsOf,
Graph,
GraphBody,
GraphProse,
GraphRule,
hasHost,
isHost,
textOf,
} from "@/registry/default/graph-frame/graph-frame"
import {
fadeUp,
staggerList,
toneClass,
type GraphPalette,
} from "@/registry/default/graph-frame/graph-motion"
import { cn } from "@/lib/utils"
type EndpointParam = {
name: string
type?: string
/** Markdown. */
description?: ReactNode
required?: boolean
}
type EndpointBlock = {
/** Muted, above the block. Defaults to the fence language. */
label?: string
code: string
}
type EndpointProps = {
/** Default `endpoint`. */
title?: string
/** Or the first line of the children: `POST /v1/graphs`. */
method?: string
path?: string
/** Data form. Or a Markdown table: name, type, description. */
params?: EndpointParam[]
/** Data form. Or fenced blocks in the children. */
blocks?: EndpointBlock[]
/**
* Markdown. `POST /v1/graphs`, a sentence, a table of params (bold name is
* required), then fenced request / response blocks.
*/
children?: ReactNode
palette?: GraphPalette
corner?: string
className?: string
}
const ROUTE = /^\s*(GET|POST|PUT|PATCH|DELETE|HEAD|OPTIONS|QUERY)\s+(\S+)\s*$/i
function cellsOf(row: ReactElement) {
return elementsOf(childrenOf(row)).filter((cell) =>
isHost(cell, ["td", "th"])
)
}
function paramsOf(table: ReactElement | undefined): EndpointParam[] {
if (!table) {
return []
}
const sections = elementsOf(childrenOf(table))
const body =
sections.find((section) => isHost(section, "tbody")) ??
sections.find((section) => !isHost(section, "thead"))
const rows = elementsOf(body ? childrenOf(body) : null).filter((row) =>
isHost(row, "tr")
)
return rows.map((row) => {
const [name, type, ...rest] = cellsOf(row)
return {
name: name ? textOf(childrenOf(name)).trim() : "",
type: type ? textOf(childrenOf(type)).trim() || undefined : undefined,
description: rest[0] ? childrenOf(rest[0]) : undefined,
required: name ? hasHost(childrenOf(name), ["strong", "b"]) : false,
}
})
}
function blocksOf(elements: ReactElement[]): EndpointBlock[] {
return elements
.filter((element) => isHost(element, "pre"))
.map((pre) => {
const code = elementsOf(childrenOf(pre)).find((element) =>
isHost(element, "code")
)
const className = (code?.props as { className?: unknown } | undefined)
?.className
const language =
typeof className === "string"
? className.match(/language-(\S+)/)?.[1]
: undefined
const text = textOf(pre).replace(/\n$/, "")
return {
label: /^\s*(\$ |curl\b)/.test(text) ? "request" : language,
code: text,
}
})
}
/**
* One API route. Markdown:
*
* ````mdx
* <Endpoint>
*
* POST /v1/graphs
*
* Draws a graph from props. Returns the fenced ASCII.
*
* | Field | Type | |
* | --- | --- | --- |
* | **slug** | string | `graph-timeline`, `graph-table`, … |
* | props | object | Same shape as the React API |
*
* ```json
* { "ascii": "+--- [ NIGHT ] ---+" }
* ```
*
* </Endpoint>
* ````
*/
function Endpoint({
title = "endpoint",
method: methodProp,
path: pathProp,
params: paramsProp,
blocks: blocksProp,
children,
palette,
corner,
className,
}: EndpointProps) {
const reduce = useReducedMotion()
const item = fadeUp(reduce)
const list = staggerList(reduce, 0.04)
const elements = elementsOf(children)
const paragraphs = elements.filter((element) => isHost(element, "p"))
const route = paragraphs
.map((paragraph) => textOf(paragraph).match(ROUTE))
.find(Boolean)
const method = (methodProp ?? route?.[1] ?? "GET").toUpperCase()
const path = pathProp ?? route?.[2] ?? "/"
const about = paragraphs.filter((paragraph) => !ROUTE.test(textOf(paragraph)))
const params =
paramsProp ?? paramsOf(elements.find((element) => isHost(element, "table")))
const blocks = blocksProp ?? blocksOf(elements)
const anyRequired = params.some((param) => param.required)
const accent = toneClass(palette, "primary")
return (
<Graph className={className} corner={corner} title={title}>
<GraphBody className="flex flex-col gap-4">
<motion.div
className="flex flex-col gap-3"
initial={reduce ? false : "hidden"}
variants={item}
viewport={{ once: true, amount: 0.4 }}
whileInView="show"
>
<p className="flex min-w-0 items-baseline gap-3">
<span className={cn("shrink-0", accent)}>{method}</span>
<span className="min-w-0 break-all text-foreground">{path}</span>
</p>
{about.length > 0 ? (
<GraphProse className="text-graph-muted">{about}</GraphProse>
) : null}
</motion.div>
{params.length > 0 ? (
<>
<GraphRule />
<motion.ul
role="list"
className="flex flex-col gap-2"
initial={reduce ? false : "hidden"}
variants={list}
viewport={{ once: true, amount: 0.3 }}
whileInView="show"
>
{params.map((param, index) => (
<motion.li
className="grid grid-cols-[1.25rem_minmax(0,11rem)_minmax(0,7rem)_minmax(0,1fr)] items-baseline gap-x-3 max-sm:grid-cols-[1.25rem_minmax(0,1fr)_auto]"
key={`${param.name}-${index}`}
variants={item}
>
<span
aria-hidden="true"
className={cn(
"text-center select-none",
param.required ? accent : "text-transparent"
)}
>
{param.required ? "*" : " "}
</span>
<span className="truncate text-foreground">
{param.name}
{param.required ? (
<span className="sr-only"> (required)</span>
) : null}
</span>
<span className="truncate text-graph-muted">
{param.type ?? ""}
</span>
{param.description ? (
<span className="min-w-0 max-sm:col-span-2 max-sm:col-start-2">
<GraphProse className="text-foreground/80">
{param.description}
</GraphProse>
</span>
) : null}
</motion.li>
))}
</motion.ul>
{anyRequired ? (
<p aria-hidden="true" className="text-graph-muted">
<span className={accent}>*</span> required
</p>
) : null}
</>
) : null}
{blocks.map((block, index) => (
<motion.div
className="flex min-w-0 flex-col gap-3"
initial={reduce ? false : "hidden"}
key={index}
variants={item}
viewport={{ once: true, amount: 0.3 }}
whileInView="show"
>
<GraphRule />
{block.label ? (
<p className="text-graph-muted">{block.label}</p>
) : null}
<div className="graph-scroll-x">
<pre className="m-0 min-w-max leading-relaxed whitespace-pre text-foreground/80">
<code>{block.code}</code>
</pre>
</div>
</motion.div>
))}
</GraphBody>
</Graph>
)
}
export { Endpoint }
export type { EndpointBlock, EndpointParam, EndpointProps }
